Samsung 34" Curve High Multi-taskers
Enhanced visual clarity and detail
Ultra WQHD
The CH89 has a screen resolution of 3440x1440—approximately 2.5 times the pixel density of Full HD—that delivers razor-sharp images. You can see more details at a glance and have a panoptic view of large web pages and documents with less scrolling and zooming.
Shake off the dual-monitor inconvenience
21:9 Aspect Ratio
The 34’’ ultra-wide curved monitor CH89 is ideal for multi-taskers who need more on-screen space for their big ideas but want to do away with the hassle of dual-monitor setups. With its ultra-wide display you can experience truly seamless single-monitor multitasking.
PBP Dual-Screen Function
Samsung’s Picture-by- Picture capabilities let you connect to two different devices at the same time while still maintaining the original image quality.
PIP Sub-Screen Display
The Picture-in- Picture feature allows you to do away with the need for a second monitor even when you are multitasking. You can resize the second image up to 25% of the screen and position it anywhere you wish.
For your viewing comfort
1800R Curvature
Engineered to match the natural curvature of the human eye, the CH89 gives you a comfortable and engrossing view of onscreen content. Plus, Samsung’s Flicker Free technology and the blue light-reducing Eye Saver Mode add to your visual comfort with reduced eye fatigue.
USB Type-C – It’s an ultimate hub
Ultimate connectivity with a single-cable
The USB type C port enables you to power, send data and even display signals between devices with just one connection. Its single connection architecture enables you to enjoy a work environment that is clutter-free as well as stress-free.
Free up USB 3.0 ports for other uses
Besides a dedicated USB type-C port for any computer including your MacBook or mobile device, you can also use your USB 3.0 ports for multiple peripherals without needing extra hubs.
Extend your mobile device
Experience your Galaxy S8 and Note 8 in a whole new way by connecting to a Samsung USB Type-C monitor without needing any hubs or apps. The larger screen will increase your enjoyment and productivity, especially when sharing with others at home or work.
Increase your ergonomic efficiency
It swivels, tilts, and is height-adjustable. VESA-supported, it can be installed on a wall or separate arms with ease. With these functions at your disposal, you can effortlessly position your screen at whatever height and angle you want and share the onscreen content with nearby coworkers.
Performance meets beauty
Slim-bodied and bezel-less on three sides, coming complete with a graceful yet steadfast height-adjustable Y stand, the CH89 is a perfect blend of performance and beauty. Its clean back design incorporates a hatch to keep cables neatly hidden out of sight.
A better way to multitask
Easy setting box S/W
With Easy Setting Box, you can easily partition your display, or place multiple displays of various sizes in different positions‡ Picture-by-Picture function lets you to display outputs from two devices. With the CH89, you can better handle the efficiency challenges of your multitasking environment.
Easy Manual Adjustment
You can also freely adjust the size of the windows as desired in the selected layout. Feel free to find totally new ways to work and play with this optimal and convenient customization tool.
Specifications
| Category | Details |
|---|---|
| Screen Size (Inch) | 34.0 |
| Screen Size (cm) | 86.4 |
| Screen Size (Class) | 34 |
| Flat / Curved | Curved |
| Active Display Size (HxV) (mm) | 797.22 x 333.72 |
| Screen Curvature | 1800R |
| Aspect Ratio | 21:9 |
| Panel Type | VA |
| Brightness (Typical, cd/m2) | 300cd/m2 |
| Brightness (Min, cd/m2) | 250cd/m2 |
| Contrast Ratio Static | 3000:1(Typ), 2400:1(Min) |
| Contrast Ratio (Dynamic) | Mega ∞ |
| Resolution | 3,440 x 1,440 |
| Response Time | 4(GTG)ms |
| Viewing Angle (H/V) | 178°/178° |
| Color Support | 16.7M |
| Refresh Rate | 100Hz |
General Feature
| Feature | Available |
| Samsung MagicBright | Yes |
| Samsung MagicUpscale | Yes |
| Eco Saving Plus | Yes |
| Eye Saver Mode | Yes |
| Flicker Free | Yes |
| Picture-In-Picture | Yes |
| Picture-By-Picture | Yes |
| Game Mode | Yes |
| Image Size | Yes |
| Easy Setting Box | Yes |
| Windows Certification | Windows 10 |
| FreeSync | Yes |
Interface
| Port | Availability |
| Wireless Display | No |
| D-Sub | No |
| DVI | No |
| Dual Link DVI | No |
| Display Port | 1 EA |
| Display Port Version | 1.2 |
| Display Port Out | No |
| Mini-Display Port | No |
| HDMI | 1 EA |
| HDMI Version | 2.0 |
| Audio In | No |
| Headphone | Yes |
| USB Ports | 3 |
| USB Hub Version | 2.0x2, 3.0x1 |
| USB-C | 1 EA |
Audio
| Feature | Availability |
| Speaker | No |
| USB Sound Bar (Ready) | No |
Operation Conditions
| Condition | Range |
| Temperature | 10~40 ℃ |
| Humidity | 10~80% (non-condensing) |
Design
| Feature | Details |
| Color | Dark Silver |
| Stand Type | HAS |
| HAS (Height Adjustable Stand, mm) | 135.0 ± 5.0 mm |
| Tilt | -5.0° ( ±2.0°) ~ +24.0° ( ±2.0°) |
| Swivel | -30.0° (-2.0°) ~ +30.0° (+2.0°) |
| Wall Mount | 100.0 x 100.0 |
Power
| Feature | Details |
| Power Supply | AC 100~240V |
| Power Consumption (Max) | 175W |
| Power Consumption (DPMS) | Less than 0.5W (HDMI/DP Input Condition) |
| Power Consumption (Off Mode) | Less than 0.3W |
| Type | Internal Power |
Dimension
| Measurement | Details |
| Set Dimension with Stand (WxHxD, mm) | 811.4 x 538.9 x 298.6 mm |
| Set Dimension without Stand (WxHxD, mm) | 811.4 x 361.9 x 123.3 mm |
| Package Dimension (WxHxD, mm) | 946.0 x 270.0 x 459.0 mm |
Weight
| Measurement | Details |
| Set Weight with Stand | 7.9 kg |
| Set Weight without Stand | 6.3 kg |
| Package Weight | 11.3 kg |
Accessory
| Accessory | Included |
| Power Cable Length | 1.5 m |
| HDMI Cable | Yes |
| USB Type-C Cable | Yes |
| Install CD | Yes |
| Quick Setup Guide | Yes |
| SKU | LC34H890WJMXZN |
|---|---|
| Brands | Samsung |
| Monitor Type | Business |
| Screen Size | 35 Inch |
| Response Time | 4ms (GTG) |
| Color | Silver |
