LG GSPA066 6.67mm Outdoor LED Screen Display
LG GSPA066 6.67mm Outdoor LED Screen Display – Long-Range Visibility for Large Outdoor Signage
The LG GSPA Outdoor LED Series is engineered for long-distance visibility and large-scale installations, making it a powerful solution for billboards, building façades, commercial plazas, and high-elevation signage. With outstanding brightness, flexible installation options, and high energy efficiency, the GSPA series delivers exceptional outdoor performance in any condition.
Long-Range Visibility for Large Outdoor Displays
Designed for mid-to-high building exteriors and long-distance viewing, the GSPA P6.6 and P10 models ensure your content stays clear, vibrant, and readable from far away. Whether used for a large billboard or a tall building frontage, the display maintains crisp text, vivid colors, and strong visual impact.
Enhanced Energy Efficiency
The GSPA series offers a 21% reduction in power consumption compared to LG’s previous model—while maintaining the same brightness levels*.
This remarkable improvement helps businesses:
- Lower long-term operating costs
- Maintain bright, high-performance visuals
- Reduce energy waste without compromising quality
Flexible Installation for Any Structure
The GSPA series offers two cabinet sizes, enabling your LED display to be configured in nearly any shape or dimension.
Key benefits include:
- Fits large surfaces, architectural walls, and cornered areas
- Supports L-shaped installations using side-cut cabinets
- Allows seamless integration with modern building designs
- Smooth and uniform content playback across the entire screen
Perfect for both standard and creative outdoor installations.
High Brightness Options for Direct Sunlight
To match different outdoor environments and regulatory requirements, the GSPA series is available in multiple brightness configurations:
- P10 – 10,000 nits (ultra high brightness)
- P10 – 8,000 nits
- P6.6 – 8,000 nits
- P6.6 – 6,000 nits
These options allow you to tailor your display for:
- Intense sunlight
- Regional climate conditions
- Energy consumption targets
- Local regulations
- Long operating hours
The P10 model can operate reliably at temperatures up to 60°C and at altitudes up to 5,000 meters.
Compatible with LG Software Solutions
When paired with LG’s CVGA system controller, the GSPA Outdoor LED Signage supports:
- LG SuperSign CMS – for easy content management
- LED Assistant – for detailed LED performance control
- LG ConnectedCare* – for remote monitoring and maintenance
Pitch Name | P6.6 |
| Pixel Pitch (mm) | 6.67 |
| Pixel Configuration | Single SMD |
| Module Resolution (W x H) | 72 × 48 |
| Module Dimensions (W x H, mm) | 480 × 320 |
| Weight per Module (kg) | 1.65 |
| Cabinet Resolution (W × H) | 144 × 144 (-GA/GAC, GE/GEC) |
| 72 × 48 (-GB/GBC, -GF/GFC) | |
| Cabinet Dimensions (W × H × D, mm) | 960 × 960 × 68 (-GA/GAC, GE/GEC) |
| 480 × 320 × 68 (-GB/GBC, -GF/GFC) | |
| No. of Modules per Cabinet (W × H) | 2 × 3 (-GA/GAC, GE/GEC) |
| 1 × 1 (-GB/GBC, -GF/GFC) | |
| Cabinet Surface Area (m²) | 0.92 (-GA/GAC, GE/GEC) |
| 0.15 (-GB/GBC, -GF/GFC) | |
| Weight per Cabinet (kg/cabinet) | 20.5 (-GA/GAC, GE/GEC) |
| 5 (-GB/GBC, -GF/GFC) | |
| Weight per Square Meter (kg/m²) | 22.5 (-GA/GAC, GE/GEC) |
| 32 (-GB/GBC, -GF/GFC) | |
| Physical Pixel Density (pixels/m²) | 22,500 |
| Flatness of Cabinet | ±0.5 |
| Cabinet Material | Aluminum |
| Service Access | Front and Rear |
Optical SpecificationsMax. Brightness (After Calibration)8,000 (-GA/GAC, -GB/GBC)6,000 (-GE/GEC, -GF/GFC)Color Temperature3,200-9,300 (K)Visual Viewing Angle (Horizontal/Vertical)160 × 140Brightness Uniformity0.97Color Uniformity±0.003 Cx, CyContrast Ratio15,000 : 1Processing Depth (bit)14 (HDR10, HDR10 Pro)
Electrical SpecificationsPower Consumption (W/Cabinet, Max.)580 (-GA/GAC, GE/GEC)100 (-GB/GBC, -GF/GFC)Power Consumption (W/Cabinet, Avg.)193 (-GA/GAC, GE/GEC)33 (-GB/GBC, -GF/GFC)Power Consumption (W/m², Max.)630 (-GA/GAC, GE/GEC)650 (-GB/GBC, -GF/GFC)Heat Dissipation (BTU/h/Cabinet, Max.)1,583 (-GA/GAC, GE/GEC)273 (-GB/GBC, -GF/GFC)Heat Dissipation (BTU/h/Cabinet, Avg.)526 (-GA/GAC, GE/GEC)90 (-GB/GBC, -GF/GFC)Heat Dissipation (BTU/h/㎡, Max.)1,720 (-GA/GAC, GE/GEC)1,774 (-GB/GBC, -GF/GFC)Power Supply (V)100 to 240Frame Rate (Hz)50 / 60Refresh Rate (Hz)3,840
Operation ConditionsLifetime (Hours to Half Brightness)100,000Operating Temperature (°C)-30 to +50Operating Humidity10-90% RHIP rating Front / RearIP66 / IP66
CertificationCertificationCE, CB, ETL, FCC, BIS, KC (TBD)Fire ProtectionBS476 Part7 Class1, EN13501-1 Class C (TBD)
EnvironmentRoHS, REACH, UAE RoHS
ControllerCVGA
90 Degree Corner CutYes (GSPA066-GAC, -GBC, -GEC, -GFC)
| SKU | GSPA066 |
|---|---|
| Brands | LG |
| Brightness | 8000 Nits |
| Contrast Ratio | 3000 : 1 |
| LED Pixel Pitch | 6.67 mm |
| LED Cabinet Size | 960 × 960 mm |
| Module Size | 480 × 320 mm |
| Color | Black |
| Weight | 22.000000 |
