Hisense HAIO138 138-inch LED All in One Display

Hisense HAIO138 138-inch LED All in One Display

Create the ultimate immersive AV experience for your boardroom with the Hisense All-In-One LED display. Delivering vivid detail and unrivaled color depth, the All-in-one 138” LED display will provide the finishing touch to any quality meeting space.Multiple Installation Options

Designed to be Installed either on a trolley/motorized stand or wall mounted.

Simple power connection

No distribution box and no need for complex power connections.

Specifications

• Pixel Pitch: 1.59 mm
• Pixel Configuration: 3 in one SMD
• Screen Resolution: 1,920 x 1,080
• Screen Dimensions (W x H x D) (mm): 3064 x 1723 x 34mm
• (w/o Screen Frame)
• Physical Resolution of Module: 80 x 120
• Physical Resolution of Panel: 320 x 360
• LED Module Dimensions (mm): 127.5 x 191.25mm
• No. of Cabinet Per Screen: 4 x 3
• No. of Modules Per Cabinet: 6 x 3
• Panel Dimensions (mm): 510 x 573.75 x 34mm
• Screen Weight: 195Kg (w/o Screen Frame)
• Cabinet Material: Die-cast Aluminum
• Gray Level (bit): 14 bits
• Aspect Ratio: 16:9

• Brightness (adjustable): 500 nits
• Contrast Ratio: 3,000 : 1
• Visual Viewing Angle (H x V): 160° x 160°
• Brightness Uniformity: 95%
• Color Uniformity: ± 0.003 Cx,Cy
• Processing Depth: 16 bits
• Color Temperature - Default (Adjustable): 6500 ± 200 K (2,000 ~ 9,300 K)

• Power Supply Voltage: 100 - 240 V
• Average Power Consumption (W/ Screen): ≤ 1000
• Max Power Consumption (W / Screen): ≤ 2200
• Refresh Rate: 3,840 Hz

• Operating Temp/Humidity: -20 - 40 °C/ 10% - 90%RH (no frost)
• Storage Temp/Humidity: -20 - 40 °C/ 10% - 65%RH (no frost)
• IP Rating: IP50
• Expected LED Lifetime (Max): 100,000 Hrs

• Built-in: 15W x4
• External: 3.5-mm AUDIO external sound system connector (before
• the built-in sound system connector)

• OS: Android 9.0
• CPU: CA73 x 4 1.3GHz
• GPU: G52 MC1
• DDR: 3GB
• ROM: 64GB
• Language: English

• Curve Support (-: concave +: convex): Flat
• Certification

• CCC, CE, CB

• Built-in

Brightness nits

With up to 500 nits maximum brightness, the display panels can deliver amazingly vivid imagery anywhere during daytime and nighttime conditions.

160° High viewing angle

The extra wide 160° viewing angle is a perfect fit for large groups of people that will view the displays from diverse angles while passing by.

High refresh rate

With uniform color scale and brightness, the dynamic performance of LED display could restore the true scenes without any ripples.

Effortless set-up and maintenance

Easy access allows for effortless setup, operation, and maintenance.

Full array local dimming

Local dimming reduces backlight intensity in specific areas of the screen to improve the contrast ratio.

HRC12 grade multi-layer protection

Dustproof, waterproof, anti-static, anti-knock, and anti-salt spray.
