BenQ MS506 SVGA Projector

Disruption-Free Learning for Small and Medium-Sized Classroom

Featuring an brightness of 2700 ANSI lumens, ultra-sharp contrast ratio of 13000:1 and a XGA resolution, the cost-effective and eco-friendly MX503 offers a stunning full-screen presentation with the finest details regardless of the ambient light level.

Specification

Projection System: DLP
Native Resolution: XGA(1024 x 768)
Brightness*: 2700 ANSI lumens
Contrast Ratio: 13000:1
Display Color: 1.07 Billion Colors
Lens: F=2.56-2.8, f=21-23.1mm
Aspect Ratio: Native 4:3 (5 aspect ratio selectable)
Throw Ratio: 1.86 - 2.04 (53”@2m)
Image Size (Diagonal): 40”-300”
Zoom Ratio: 1.1:1
Lamp Type: 190W
Lamp(Normal/Economic Mode/SmartEco Mode)*:
4500/6000/6500 hours
Keystone Adjustment: 1D, Vertical +/- 40 degrees
Projection Offset: 120%
Resolution Support: VGA(640 x 480) to UXGA(1600 x 1200)
Horizontal Frequency: 31K~102KHz
Vertical Scan Rate: 23~120Hz

Interface

Computer in (D-sub 15pin) x 2(shared with Component)
Monitor out (D-sub 15pin) x 1
Composite Video in (RCA) x 1
S-Video in (Mini DIN 4pin) x 1
Audio in (Mini Jack) x 1
Audio out (Mini Jack) x 1
Speaker 2W x 1
USB (Type Mini B) x 1
RS232 (DB-9pin) x 1

Dimensions(W x H x D): 287.3x114.4x 232.6 mm
HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility: NTSC, PAL, SECAM
Weight: 2.3kg (5.29lbs)
Audible Noise: 30/26 dBA (Normal/Economic mode)
Power Supply: AC 100 to 240 V, 50/60 Hz
Power Consumption: 275W, Standby<0.5W

On-Screen Display Languages (28 Languages)

English/ France/ Germany/ Italian/ Spanish/ Russian/ Traditional Chinese/ Simplified Chinese/ Japanese/ Korean/ Swedish/ Dutch/ Turkish/ Czech/ Portuguese/ Thai/ Polish/ Hungarian/ Croatian/ Romanian/ Norwegian/ Danish/ Bulgaria/ Finnish/ Indonesian/ Greek/ Hindi/ Arabic

Picture Modes

• Dynamic/Presentation/sRGB/Cinema/User 1/User 2

Accessories (Standard)

• Remote Control w/ Battery
• Power Cord (by region)
• User Manual CD
• Quick Start Guide
• Warranty Card (by region)
• VGA(D-sub 15pin) Cable

Accessories (Optional)

• Presentation Plus P/N: 65.J9306.002
• Spare Lamp Kit P/N: 5J.J6D05.001
• Ceiling Mount P/N: 5J.J2K01.001
• 3D Glasses P/N: 5J.J0T14.011
• Carry Bag P/N: 5J.J3T09.001

3D Support and Compatibility

PC: 120Hz Frame Sequential 3D for resolutions up to WXGA
