The ViewBoard® IFP50 series embraces ultra fine touch technology to offer fine precision writing. Along with slim IR touch and its optimized integration, the processing time is faster than traditional IR panels. Meanwhile, smooth dual-pen writing with our new, slim 3mm pens enables teachers and students to work efficiently on any detailed tasks that require the accurate use of fine tipped pens during group discussion. On top of that, the ViewBoard® IFP50 series is designed with a slim bezel to broaden your viewing experience, so that even at the edge you can write clearly and thinly. It is also well integrated with myViewBoard™ whiteboarding software to collaborate on the go, and further complimented by ViewBoard® Cast software for 4 way split screen content sharing.
Ultra Fine Touch Technology
It provides fine precision writing with a 3mm diameter pen tip
Dual-Pen
Automatically detect pen diameter (8mm & 3mm) and write simultaneously with different colours and thicknesses.
Full Native Performance on Android
Built-in myViewBoard® whiteboarding software to collaborate on the go
4-way Split Screen
4-way split screen content sharing with built-in ViewBoard® Cast software.
Shared USB Ports
SmartPort™ shared front USB ports for internal & external PCs.
Stereo Sound
2.1 Stereo sound with a built-in subwoofer.
Faster Internet
GigaLAN provides a faster, more powerful internet connection.
Remote Control
Built-in RS232 port and vController software for remote control.
Slot-in PC
Slot-in PC with Intel 8th-gen CPU (Optional).
Web Camera
Top-mounted 1080p web camera (Optional).
Display
Specification
Details
Panel Size
55"
Type/Tech
TFT LCD Module with DLED Backlight
Display Area (mm)
1209.6(H) x 680.4(V) (54.64” diagonal)
Aspect Ratio
16:9
Native Resolution
UHD 3840x2160 (Pixels)
Colours
1.07B colours (10-bit)
Brightness
350 nits (typ.), 300 nits (min.)
Contrast Ratio
5000:1 (DCR)
Response Time
8ms
Viewing Angles
H = 178, V = 178 (typ.)
Backlight Life
30,000 Hours (Min)
Surface Treatment
Anti-Glare
Bezel
Slim
Orientation
Landscape
Platform
Specification
Details
Processor
ARM Cortex A73 dual-core 1.2GHz
RAM
2GB DDR4
Storage
16GB
Touch
Specification
Details
Type/Tech
IR Recognition
Touch Resolution
32767 x 32767
Touch Points
20 points touch, 10 points writing
Input
Specification
Details
HDMI
2.0 x3 (3840x2160 @60Hz)
RGB / VGA
x1
Audio
x1 (PC audio in)
CVBS
x1
RS232
x1
OPS
x1 PC Slot (proprietary)
Output
Specification
Details
HDMI
x1
Audio
x1 (Earphone out)
SPDIF
1 (optical)
LAN
Specification
Details
RJ45
x1
USB
Specification
Details
Type A
USB 2.0 x4 (including 2 USB ports in front)
USB 3.0
x2 (including 1 USB port in front)
Type B
x2, for touch
Audio & Camera
Specification
Details
Speakers
10W x2 + 15W x1
Embedded OS & Software
Specification
Details
Embedded OS
Android 7
Basic Annotation Software
myViewBoard / vBoard Lite
Pro Annotation Software
myViewBoard for Windows (Embedded in Windows Slot-in PC)
